ASTM DIN JIS BS 0.14-0.20MM Red Coated Aluminum Zinc 18 Gauge 24 Gauge Corrugated Galvanized Sheet Gi Iron Roofing Sheet

Product Detail

Processing service:Welding, punching, cutting, bending, uncoilingstandard:ASTM/DIN/JIS/BS/GB/T
Shape Type:Steel coil, hot dip galvanized steel coilweight:2.5---4.5kg/m2
application:buildings, warehouses, roof structures, wallshardness:full hard
Packaging Details:Standard Sea Resistant Packaging Cold Rolled Stainless Steel Coil Stainless Steel Coil Knife Stainless Steel Coil Coil Cold Rolledsurface:Hot dip galvanized, painted
brand:Zhong Xianglength:1400-1799mm, 1800-2000mm, 2001-3600mm, 3601-3660mm
thickness:0.14-0.20MMCoating Type:(PVDF,PVF2,PE)
Applicable slope:10 degrees-90 degreesSupply capacity:1000 tons/month
payment terms:L/C,Western Union,D/P,D/A,T/T,MoneyGramPackaging Preview:
Scope of application:Factory warehouse fence construction and workshop renovationgrade:DX51D,DX52D,DX53D,DX54D,S250GD,S350GD,S550GD
technology:cold rolled hot rolledtolerant:±5%, ±1%, ±10%
port:Qingdao, Shanghai, Tianjin, etc.delivery time:15-21 days
proper temperature:-50℃-70℃Sequin Type:minimal sequins
width:1221-1500mmplace of origin; place of origin:Shandong China
Zinc coating:30-275 g/m²Certificate:API, CE, ISO9001
coating:Z61-Z90Tensile/Bending Strength:29.4mpa/ 45.6mpa
Product Description
ASTM DIN JIS BS 0.14-0.20MM Red Coated Aluminum Zinc 18 Gauge 24 Gauge Corrugated Galvanized Sheet Gi Iron Roofing Sheet
product name
Corrugated steel roof panel
Material
DX51D,DX52D,DX53D,DX54D,S250GD,S350GD,S550GD
thickness
0.12-6mm
type
460/760/750/820/840/900/850/880/960/980/1050
standard
ASTM/DIN/JIS/BS/GB/T
Zinc coating
30-275 g/m²
width
600-1500mm, usually 1250mm, 1000mm, 1240mm, 1500mm, 914mm, 750mm, etc.
grade
TDX51D+Z, TDX51D+AZ
application
Villas, Townhouses, Apartments, Destination Architecture, Roof Renovations
Paint back (microns)
5-10 microns
surface treatment
1. Galvanized
2. PVC, black and painted
3. Transparent oil, anti-rust oil
4. According to customer requirements
coating
AZ30-AZ160, Z50-Z140g/m2
surface
Matte, Glossy, Double Coat, Woodgrain, Marbled, Wrinkle
1. Color: RAL, NCS, PANTONE and other international colors are optional, any color can be according to customer requirements
2. Coating types can be selected (PVDF, PVF2, PE)
The types of coatings generally use PVDF fluorocarbon coatings containing more than 70% of fluorocarbon resins. Require.
2.1. Hot-dip galvanized color-coated steel sheet (color-coated steel sheet)
The product obtained by applying an organic coating on a hot-dip galvanized steel sheet is a hot-dip galvanized color-coated sheet.
In addition to the protective effect of zinc, the hot-dip galvanized color-coated sheet also has an anti-rust effect.
The service life is longer than that of hot-dip galvanized sheet;

2.2. Hot-dip aluminum-zinc color-coated sheet (color-coated aluminum-zinc-coated steel sheet)
Hot-dip Al-Zn steel sheets can also be used as color-coated substrates (55% AI-Zn and 5% AI-Zn);

2.3. Electro-galvanized color-coated sheet Using electro-galvanized sheet as the base material, the product obtained by baking with organic coating is electro-galvanized color-coated sheet. Beautiful appearance, excellent processing performance, mainly used in home appliances, audio, steel furniture, interior decoration and so on.
Product display
1. Light weight; The density of aluminum is 2.73g/cm³, which is 1/3 of that of steel.
2. High strength; high strength can be achieved through synthesis, processing and heat treatment.
3. Corrosion resistance; It has self-rust property, forms an oxide layer, can prevent metal oxidation and rust, and is resistant to acid and alkali.
4. The surface treatment is diverse and beautiful. Can be anodized, electrophoretic, chemically treated, polished, painted
treat.
1. Good plasticity, easy to process
2. Good conductivity. Non-magnetizing and low spark susceptibility to prevent electromagnetic interference and reduce flammability under special conditions.
3. Easy installation; aluminum metal can be connected by riveting, welding, gluing, etc.
4. Environmentally friendly, 100% recyclable.
application
Suitable for industrial and civil buildings, warehouses, special buildings, long-span steel structure house roofs, walls and
Interior and exterior wall decoration, light weight, high strength, rich colors, convenient construction, earthquake resistance, fireproof, rainproof, long
Long life and maintenance free
Our advantage
(1) Quality Zhongxiang Steel introduces advanced testing equipment, sets up a professional scientific research team, and strictly controls the quality of every link of production. Including incoming inspection of raw materials, color analysis of products during production, T-bend test, impact test, salt spray test, tensile test and packaging test of export products, etc., to ensure the comprehensive performance of products such as corrosion resistance and coating viscosity. Safe transportation.
(2) Service Today, when economic globalization promotes international operation, our company has gone to many countries and regions to participate in steel industry exhibitions. Our products are not only sold well in the domestic market, but also exported to Europe, such as Southeast Asia, Russia, Ukraine, the United States, Ireland, Singapore, Dubai, Colombia and other countries and regions, winning the trust and praise of customers and successfully transitioning from domestic to foreign countries.
