A36 standard steel c channel bracket galvanized steel h beam profile
-
$520.00 / 1 - 24 pieces
$480.00 / 25 - 99 pieces
$450.00 / >=100 pieces - 1 piece
- Wuxi Xyt Metal Material Co., Ltd.
- Jiangsu, China
- Mr Leon zhao
Product Detail
Processing service: | Welding, bending, punching, uncoiling, cutting | place of origin; place of origin: | Jiangsu, China |
brand: | XYT | model: | Carbon steel I-beam |
Key words: | Structural I-beam | Material: | SS400 SS490 S235JR S275JR A36 |
tolerant: | ±1% | bill: | by actual weight |
grade: | A36 - A572 | Technical: | Hot Roll Forming |
port: | Shanghai Qingdao Tianjin | delivery time: | within 7 days |
application: | building structure | Alloy or not: | non-alloy |
Supply capacity: | 100,000 tons/month | payment terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram |
standard: | Aisi | length: | 6-12m |
Packaging Preview: |
H-beam is an economical and high-efficiency steel with more optimized cross-sectional area distribution and more reasonable strength-to-weight ratio. It is named after its cross section is the same as the English letter "H". Since the various parts of the H-beam are arranged at right angles, the H-beam has the advantages of strong bending resistance, simple construction, cost saving, and light weight in all directions, and has been widely used. Representation of hot-rolled H-beams. H-beams are divided into three categories: wide-flange H-beams (HK), narrow-flange H-beams (HZ) and H-beam piles (HU). Height H×width B×web thickness t1×flange thickness t2, such as H-beam Q235B, SS400 200×200×8×12 200mm width 200mm web thickness 8mm, flange thickness
product name | Carbon steel H-beam |
standard | ASTM,JIS,DIN EN10025,GB |
Certificate | ISO, SGS, CE or other third party inspections are acceptable. |
material grade | Q195-Q420 series, SS400-SS540 series, S235JR-S355JR series, |
ST series, A36-A992 series, Gr50 series | |
high leg | 100mm-630mm |
depth | 68mm-180mm |
thickness | 4.5mm-17mm |
length | 1000mm-12000mm |
technology | hot rolled |
surface treatment | Bare, black, galvanized, coated, painted or as your request |
application | Industry, construction, decoration, shipbuilding, bridging, etc. |
payment terms | T/T, L/C at sight, etc. |
trade terms | Ex-works price, FOB/CFR/CIF |
delivery time | 15-20 days after receiving the deposit. |
Package | Seaworthy wooden pallet or as customer's request |
port of shipment | Tianjin |
Package | Standard export packaging or as required |
Advantage | Small MOQ+ Excellent Quality+ Competitive Price+ Fast Delivery |
Nominal size | Huaxiabao | T1 | T2 | unit weight |
(mm) | (mm) | (mm) | (mm) | (kg/m) |
100*100 | 100*100 | 6 | 8 | 16.9 |
120*120 | 125*125 | 6.5 | 9 | 23.6 |
150*75 | 150*75 | 5 | 7 | 14 |
150*100 | 148*100 | 6 | 9 | 20.7 |
150*150 | 150*150 | 7 | 10 | 31.1 |
175*90 | 175*90 | 5 | 8 | 18 |
200*100 | 198*99 | 4.5 | 7 | 17.8 |
200*100 | 5.5 | 8 | 20.9 | |
175*175 | 175*175 | 7.5 | 11 | 40.4 |
194*150 | 194*150 | 6 | 9 | 29.9 |
200*200 | 200*200 | 8 | 12 | 49.9 |
200*204 | 12 | 12 | 56.2 | |
250*125 | 248*124 | 5 | 8 | 25.1 |
250*125 | 6 | 9 | 29 | |
250*175 | 244*175 | 7 | 11 | 43.6 |
300*150 | 298*149 | 5.5 | 8 | 32 |
300*150 | 6.5 | 9 | 36.7 | |
300*200 | 294*200 | 8 | 12 | 55.8 |
298*201 | 9 | 14 | 65.4 | |
350*175 | 346*174 | 6 | 9 | 41.2 |
350*175 | 7 | 11 | 49.4 | |
400*200 | 396*199 | 7 | 11 | 56.1 |
400*200 | 8 | 13 | 65.4 | |
250*250 | 250*250 | 9 | 14 | 71.8 |
250*255 | 14 | 14 | 81.6 | |
300*300 | 300*300 | 10 | 15 | 93 |
294*302 | 12 | 12 | 83.4 | |
300*305 | 15 | 15 | 105 | |
Nominal size | Huaxiabao | t1 | t2 | unit weight |
(mm) | (mm) | (mm) | (mm) | (kg/m) |
350×350 | 344×348 | 10 | 16 | 113 |
350×350 | 12 | 19 | 135 | |
400×400 | 388×402 | 15 | 15 | 140 |
394×398 | 11 | 18 | 147 | |
400×400 | 13 | twenty one | 172 | |
400×408 | twenty one | twenty one | 197 | |
414×405 | 18 | 28 | 232 | |
428×407 | 20 | 35 | 283 | |
350×250 | 340×250 | 9 | 14 | 78.1 |
400×300 | 390×300 | 10 | 16 | 105 |
450×300 | 440×300 | 11 | 18 | 121 |
450×200 | 446×199 | 8 | 12 | 65.1 |
450×200 | 9 | 14 | 74.9 | |
500×300 | 482×300 | 11 | 15 | 111 |
488×300 | 11 | 18 | 125 | |
500×200 | 496×199 | 9 | 14 | 77.9 |
500×200 | 10 | 16 | 88.2 | |
506×201 | 11 | 19 | 102 | |
600×200 | 600×200 | 11 | 17 | 103 |
596×199 | 10 | 15 | 92.4 | |
606×201 | 12 | 20 | 118 | |
600×300 | 582×300 | 12 | 17 | 133 |
588×300 | 12 | 20 | 147 | |
594×302 | 14 | twenty three | 170 | |
700×300 | 692×300 | 13 | 20 | 163 |
700×300 | 13 | twenty four | 182 | |
800×300 | 800×300 | 14 | 26 | 207 |
808×302 | 16 | 30 | 241 | |
900×300 | 890×299 | 15 | twenty three | 210 |
900×300 | 16 | 28 | 240 | |
912×302 | 18 | 34 | 283 |
Inquiry
1. Who are we?
We are headquartered in Wuxi, China, we have a 10-year history of industrial steel, and we have a total of about 500 people in our factory. we are
production trading company
2. How do we guarantee the quality?
Always pre-production samples before mass production;
Always perform final inspection before shipment;
3. What can you buy from us?
We can provide customized services for coils, sheets, tubes and profiles.
4. Why should you buy from us instead of other suppliers?
Wuxi Xintai Steel Co., Ltd. is located in Wuxi, the capital of Jiangsu Province. The XYT metal team has been focusing on the steel industry for 10 years, with sufficient inventory, more than 100,000 tons, and a short supply cycle. At the same time, we have color coating and tile processing plants, which can process and produce products that meet your requirements and specifications as required. So our factory is your best choice in terms of price and customized service.
5. What services can we provide?
pre-sale service
1. We can provide free samples, you only need to pay the shipping cost.
2. We have sufficient stock, which can be delivered in a short time. A variety of styles are available for you to choose from.
3. OEM and ODM orders are accepted, any type of logo printing or design is available.
4. High quality + ex-factory price + quick response + reliable service is what we wholeheartedly provide for you
5. All our products are produced by our professional workers, we have our efficient foreign trade team, you can totally trust our service.
6. We have 10 years experience in steel design, manufacture and sales, we cherish every order.
after you choose
1. We will calculate the cheapest shipping and invoice you immediately.
2. Check the quality again, then send to you 1-2 working days after your payment,
3. Email the tracking no to you and help track the package until it reaches you.
After-sale option
1. We are glad that customers give us some suggestions on prices and products.
2. If you have any questions, please contact us for free by email or phone.
1. Who are we?
We are headquartered in Wuxi, China, we have a 10-year history of industrial steel, and we have a total of about 500 people in our factory. we are
production trading company
2. How do we guarantee the quality?
Always pre-production samples before mass production;
Always perform final inspection before shipment;
3. What can you buy from us?
We can provide customized services for coils, sheets, tubes and profiles.
4. Why should you buy from us instead of other suppliers?
Wuxi Xintai Steel Co., Ltd. is located in Wuxi, the capital of Jiangsu Province. The XYT metal team has been focusing on the steel industry for 10 years, with sufficient inventory, more than 100,000 tons, and a short supply cycle. At the same time, we have color coating and tile processing plants, which can process and produce products that meet your requirements and specifications as required. So our factory is your best choice in terms of price and customized service.
5. What services can we provide?
pre-sale service
1. We can provide free samples, you only need to pay the shipping cost.
2. We have sufficient stock, which can be delivered in a short time. A variety of styles are available for you to choose from.
3. OEM and ODM orders are accepted, any type of logo printing or design is available.
4. High quality + ex-factory price + quick response + reliable service is what we wholeheartedly provide for you
5. All our products are produced by our professional workers, we have our efficient foreign trade team, you can totally trust our service.
6. We have 10 years experience in steel design, manufacture and sales, we cherish every order.
after you choose
1. We will calculate the cheapest shipping and invoice you immediately.
2. Check the quality again, then send to you 1-2 working days after your payment,
3. Email the tracking no to you and help track the package until it reaches you.
After-sale option
1. We are glad that customers give us some suggestions on prices and products.
2. If you have any questions, please contact us for free by email or phone.
