Manufacturing of Titanium and Titanium Alloys

Origin: China Brand Name: QCTI
Model Number: Bar Application: Industrial
Shape: Round Length: 100-6000mm
Process: rolling Material: pure titanium and titanium alloy
Weight: 4.51g Processing method: bending, cutting
Certificate: ISO9001-2015 Surface: Polished surface

Sales unit: Single

Advantages of titanium rods
1.Light weight - [specific gravity] (60% of steel specific gravity, about 1.7 times of aluminum)
2.Low thermal expansion - [coefficient of thermal expansion] (half that of NE-18-8 stainless steel, one third of aluminum)
3.Low hear conductivity-[thermal conductivity] (almost the same as 18-8 stainless steel)
4.Low conductivity-[conductivity](about 3% of copper)
5.High elasticity-longitudinal elastic modulus] (half of iron or stainless steel, same as copper)
6.Non-magnetism -[Magnetic Permeability] (Non-magnetic material; Magnetic Permeability=1.0001)

Titanium is 30% stronger than steel, yet nearly 50% lighter. Titanium is 60% heavier than aluminum, but twice as heavy
sturdy. Titanium has excellent strength retention at 1,000 degrees Fahrenheit. Titanium is alloyed with aluminum, manganese, iron, molybdenum and other metals to increase strength, withstand high temperatures and reduce the weight of the resulting alloy. Titanium's high corrosion resistance is also a valuable property; when exposed to the atmosphere, titanium forms a tight, tough oxide film that is resistant to many corrosive substances, especially salt water.

Tier 1 Titanium is an unalloyed, low-strength titanium product with low oxygen content and high formability; this grade of titanium is used in airframes, heat exchangers and desalination units.

Titanium Grade 2It is an unalloyed medium strength titanium product. This grade of titanium is used in airframes, aircraft engines, and ship components; good weldability and corrosion resistance are notable features.

Grade III TitaniumIs an unalloyed high-strength titanium product with excellent corrosion resistance and good weldability. This grade of titanium is primarily used in airframe and aircraft engine components.

Titanium Grade IV It is the highest strength pure unalloyed titanium product. This grade of titanium is used almost exclusively in airframes, aircraft engine components, ships, surgical implants, hydraulic tubing. Good formability and corrosion resistance are its hallmarks.

Grade 5 Titanium(6AL-4V) is a titanium alloy product containing 6% aluminum and 4% vanadium; it is a medium-strength product. This grade of titanium is primarily used in airframe and turbine engine parts; and in surgical implants. Technical Information Titanium 6AL – 4V ELI is a titanium alloy product containing 6% Aluminum and 4% Vanadium, ELI (Extra Low Interstitial).

6AL–2Sn–4Zr–2Mo(6-2-4-2) is a titanium alloy product containing 6% aluminum, 2% tin, 4% zirconium and 2% molybdenum.

6AL–6V–2Sn(6-6-2) is a titanium alloy product containing 6% aluminum, 6% vanadium and 2% tin.

5AL–2.5Sn & ELI(5-2.5) is a titanium alloy product containing 5% aluminum and 2.5% tin. There is also ELI (Extra Low Interstitial).

8AL–1V–1Mo(8-1-1) is a titanium alloy product containing 8% aluminum, 1% molybdenum and 1% vanadium.

15V–3Cr–4AL–3Sn(15-3-4-3) is a titanium alloy product containing 15% vanadium, 3% chromium, 4% aluminum and 3% tin.
