ASTM A537 grade 2 carbon steel plate A537 cl2 shell plate SA 537 cl2 pressure vessel steel plate price
- $700.00 /piece
- 1 piece
- Henan Bebon Iron & Steel Co., Ltd.
- Henan, China
- Ms BBN Steel Olivia
Product Detail
Supply capacity: | 50000 tons per month | width: | 2001-3000mm |
payment terms: | L/C, Western Union, T/T | Carbon steel: | Yes |
Steel for pressure vessels: | Yes | length: | 6001-12000mm |
SGS BV inspection: | Available, other 3rd party inspections are also available | surface: | black, or customized |
port: | Shanghai Port, Qingdao Port, Tianjin Port | grade: | A537 Class 1 2 3 |
tolerant: | ±15%, ±5%, ±1%, ±20%, ±10% | standard: | ASTM |
brand: | Bebon, BBN Steel | technology: | hot rolled |
Boiler Steel: | Yes | Advantage: | Accept customized production |
Alloy or not: | is an alloy | Factory test certificate: | Provide EN10204 3.1 MTC, 3.2 MTC |
thickness: | 50.1-70mm | Invoicing: | by theoretical weight |
Origin: | Henan, China | delivery time: | 22-30 days |
Technical test: | UT test, bending test, Charpy test | product name: | A537 Grade 2 Steel Plate |
application: | boiler plate | Processing services: | Welding, punching, cutting, bending, decoiling |
Certificate: | API, PVOC, SONCAP, SABS, sirm, tisi, KS, ISO9001, ABS, BV, NK, RINA, PRS, VR, KR, CCS | product available: | Yes |
Packaging Details: | Standard export seaworthy packing or as required. |
Product Description
Boiler pressure vessel steelCoil/Sheet/Plate
ASTM A537 steel plate:A537 Class 1/A537 CL1, A537 Class 2/A537 CL2, A537 Class 3/A537 CL3
ASTM A537 steel plates are heat-treated carbon-manganese-silicon steel plates used for fusion welding of pressure vessels and structures.A537pressure vesselSteel plates can be divided into three categories:A537 Class 1, A537 Class 2, A537 Class 3.
A537 Grade 1 plate has a maximum thickness of 4 inches [100 mm], A537 Type 2 and A537 Type 3Pressure vessel steel platethicknessis 6 inches [150 mm].
A537 Grade 1 plate shall be normalized. A537 Grade 2 and A537 Grade 3 shall be quenched and tempered (Q+T).
send inquiry now
Product parameters
send inquiry now
Send product details like steel grade, size and quantity to get an accurate quotation.
Chemical composition of ASTM A537 steel plate: | ||||||||||||||||
C | silicon | manganese | P | small | copper | you | chromium | mo | ||||||||
0.24 | 0.13-0.55 | 0.64-1.72 | 0.025 | 0.025 | 0.38 | 0.28 | 0.29 | 0.09 |
Mechanical properties of ASTM A537 steel plate: | ||||||
grade | thickness | tensile strength | Yield Strength | |||
A537 Class 1 | mm | ksi [MPa] | ksi [Mpa] minutes. | |||
≤65mm | 70-90 [485-620] | 50 [345] | ||||
65-100mm | 65-85 [450-585] | 45 [310] | ||||
100-150mm | - | - | ||||
A537 Class 2 | ≤65mm | 80-100 [550-690] | 60 [415] | |||
65-100mm | 75-95 [515-655] | 55 [380] | ||||
100-150mm | 70-90 [485-620] | 46 [315] | ||||
A537 Level 3 | ≤65mm | 80-100 [550-690] | 55 [380] | |||
65-100mm | 75-95 [515-655] | 50 [345] | ||||
100-150mm | 70-90 [485-620] | 40 [275] |
standard | Boiler and Pressure Vessel Steel Grades | ||||||
ASTM A202/A202M | A202 Class A | A202 Class B | |||||
ASTM A203/A203M | A203 Class A | A203 Class B | A203 Class D | A203 Class E | |||
A203 Class F | |||||||
ASTM A204/A204M | A204 Class A | A204 Class B | A204 Grade C | ||||
ASTM A285/A285M | A285 Class A | A285 Class B | A285 Class C | ||||
ASTM A299/A299M | A299 Class A | A299 Class B | |||||
ASTM A302/A302M | A302 Class A | A302 Class B | A302 Class C | A302 Class D | |||
ASTM A387/A387M | A387 Class 5 | A387 Class 9 | A387 Grade 11 | A387 Grade 12 | |||
A387 Class 22 | A387 Class 91 | ||||||
ASTM A515/A515M | A515 Class 60 | A515 Class 65 | A515 Class 70 | ||||
ASTM A516/A516M | A516 Class 55 | A516 Class 60 | A516 Class 65 | A516 Class 70 | |||
ASTM A517/A517M | A517 Class A | A517 Class B | A517 E-class | A517 F-Class | |||
A517 Class H | A517 Class P | A517 Q-Class | A517 S-Class | ||||
ASTM A533/A533M | A533 Class A | A533 Class B | A533 Class C | A533 Class D | |||
ASTM A537A537M | A537 Class 1 | A537 Class 2 | A537 Class 3 | ||||
ASTM A612/A612M | ASTM A612M | ||||||
ASTM A662/A662M | A662 Class A | A662 Class B | A662 Class C | ||||
ASTM A841/A841M | A841 Class A | A841 Class B | A841 Class C | A841 Class D | |||
A841 Class E | A841 Class F | ||||||
EN10028-2 | P235GH | P265GH | P295GH | P355GH | |||
16Mo3 | |||||||
EN10028-3 | P275NH | P275NL1 | P275NL2 | P355N | |||
P355NH | P355NL1 | P355NL2 | P460NH | ||||
P460NL1 | P460NL2 | ||||||
EN10028-5 | P355M | P355ML1 | P355ML2 | P420M | |||
P420ML1 | P420ML2 | P460M | P460ML1 | ||||
P460ML2 | |||||||
EN10028-6 | P355Q | P355QH | P355QL1 | P355QL2 | |||
P460Q | P460QH | P460QL1 | P460QL2 | ||||
P500Q | P500QH | P500QL1 | P500QL2 | ||||
P690Q | P690QH | P690QL1 | P690QL2 | ||||
JIS G3115 | SPV235 | SPV315 | SPV355 | SPV410 | |||
SPV450 | SPV490 | ||||||
JIS G3103 | SB410 | SB450 | SB480 | SB450M | |||
SB480M | |||||||
GB 713 | Q245R | Q345R | Q370R | 18MnMoNbR | |||
15CrMoR | 14Cr1MoR | 13MnNiMoR | 12Cr2Mo1R | ||||
12Cr1MoVR | |||||||
GB3531 | 16MnDR | 15MnNiDR | 09MnNiDR | ||||
Standard 17155 | Hello | high fidelity | 17Mn4 | 19Mn6 | |||
15Mo3 | 13CrMo44 | 10CrMo910 |
