Factory Quotation DuPont Pom-100p Delrin Polyacetal Pom Resin Pom-500p Engineering Injection Polyoxymethylene Natural
- $1580.00 /piece
- 1 piece
- Hebei Yujin Technology Co., Ltd.
- Hebei, China
- Mr Jacky Yuan
Product Detail
| MOQ: | 1 ton | color: | custom made |
| application: | Automotive Industry; Industrial Machinery | port: | Tianjin |
| Package preview: | grade: | injection | |
| Material: | POM for injection molding | brand: | Yu Jin |
| filler: | as requested | Origin: | Hebei china |
| Packaging Details: | 25 kg per bag | form: | Grain; Granules; Resin |
| model: | Dupont 100P 500P | pack: | Bag |
| payment terms: | L/C, Western Union, D/P, D/A, T/T | thing: | POM for injection molding |
| Supply capacity: | 1000 metric tons per month | characteristic: | electric |
Product Description
Specification
Factory Quotation DuPont Pom-100p Delrin Polyacetal Pom Resin Pom-500p Engineering Injection Polyoxymethylene Natural
property | Test Methods | typical value | unit |
The melt flow rate | ISO 1133 @ 190°C/2.16 kg | 1.6 | g/10min |
The melt flow rate | ISO 1133 @ 210°C/2.16 kg | 3.7 | g/10min |
density | ISO 1183 | 1.19 | g/cubic centimeter |
water vapor transmission rate | ASTM E96 @ 40°C 90RH | 1.3 | |
Oxygen permeability | @ 20°C 0RH | 0.0059 | |
Oxygen permeability | @ 20°C 65RH | 0.0079 | |
Oxygen permeability | @ 20°C 85RH | 0.03 | |
tensile strength at break | ISO 527 @ 23°C | 34 | MPa |
Tensile modulus | ISO 527 @ 23°C | 2700 | MPa |
elongation at break | ISO 527 @ 23°C | 15 | % |
Flexural modulus | ISO 178 @ 23°C | 4800 | MPa |
Charpy unnotched impact | ISO179 | 2 | kJ/square meter |
hardness | ISO 2023 | Post-90s | |
crystallization temperature | ISO 11357 | 158 | |
glass transition temperature | ISO 11357 | 57 | ℃ |
Melting temperature | ISO 11357 | 183 | ℃ |
Definition of POM engineering plastics: POM is a linear polymer with no side chain, high density and high crystallinity. According to the different chemical structures in its molecular chain, it can be divided into homopolyoxymethylene and copolymerized polyoxymethylene. The important differences between the two are: homopolyoxymethylene has high density, crystallinity, and melting point, but poor thermal stability, narrow processing temperature range (about 10°C), and slightly low acid-base stability; low melting point and strength, but good thermal stability , not easy to decompose, wide processing temperature range (about 50 ℃), good acid-base stability. It is an engineering plastic with excellent comprehensive performance. It has good physical, mechanical and chemical properties, especially excellent friction resistance. Commonly known as Saigang or Duogang, it is the third largest engineering plastic. It is suitable for making wear-reducing and wear-resistant parts, transmission parts, and chemical and instrument parts.
