Cold working die GB Cr12 D3 1.2080 SKD1 stamping die with die steel round bar

Product Detail

Special Purpose:Die steelPackaging Details:New design D3 die steel bar 1.2601 cold work die steel seaworthy package; 20ft: gross weight: 17.5T; (5.80mX2.13mX2.18m,) 40ft: GW: 22T; (11.8mX2.13mX2.18m,) or according to customer Require
Alloy or not:is an alloyheat treatment:Annealing/Q+T
Name:New Design D3 Die Steel Rod 1.2601 Cold Work Die Steeltest:SGS/UT100%/element detection
brand:Song Shunexperience:Ten years of manufacturing experience
application:die steel rodtolerant:±3%
grade:steelCertificate:ISO/factory certificate
Processing services:to cutSteel grade:Cold work steel D3/ 1.2080
Origin:Guangdong, Chinatechnology:Hot Rolled/Forged/Cold Drawn
Serve:Free samples, 24 hours onlineport:Shenzhen
shape:Round bar/flat bar/platetechnology:cold drawn
Surface treatment:custom madeSupply capacity:5000 tons per month according to customer order
type:alloy steel rodpayment terms:L/C, T/T, Western Union, MoneyGram
delivery conditions:Hot rolled or forged/peeled or black surface/annealed or QTstandard:AiSi, ASTM, bs, DIN, GB, JIS
model:Cold work steel D3/ 1.2080

Cold working die GB Cr12 D3 1.2080 SKD1 stamping die with die steel round bar

1. Chemical composition

C silicon manganese P small copper
2.00-2.30 ≤0.40 ≤0.40 ≤0.030 ≤0.030 -



2. Steel equivalent

industry standard ASTM National standard English/ISO TOCT bachelor

1.2080

D3 Cr12 X210Cr12



3. Surface treatment

Sheet: original black, original cold rolled bright, machined, ground

Bars: Raw Black, Raw Rolled (Pull) Bright, Turned, Peeled, Grinded

4. Size

Round rod: diameter (mm) up to 800mm; length (mm) up to 12000mm.

Plate: Thickness (mm) Max 800mm; Width (mm) Max 2300mm; Length (mm) Max 12000mm.

Conditions: cold rolling (drawing) ≤ 50mm, hot rolling ≤ 12-250mm, hot forging ≥ 50mm. (thickness/diameter)

5. Features

Good hardenability, high-frequency quenching treatment after QT, good machinability.

6. Application

Punching dies, knife dies, screw dies, porcelain dies, etc.

application

advantage



available products

steel type

National standard

AISI/ASTM industry standard JIS CN
cold work die steel Cr12 D3 1.2080 SKD1 X210Cr12
Cr12MoV D3 1.2601 SKD11 X165CrMoV12
Cr12Mo1V1 D2 1.2379 SKD10 X153CrMoV12
9CrWMn O1 1.2510 SKS3
Hot work die steel 4Cr5MoSiV1 H13 1.2344 SKD61
4Cr5MoSiV H11 1.2343 SKD6
plastic mold steel 3Cr2Mo P20 1.2311 MCU 4
3Cr2MnS P20+S 1.2312
3Cr2NiMo P20+nickel 1.2738
4Cr13 420 1.2083 SUS420J2
4Cr16 420 1.2316 SUS420
2Cr13 420 1.4021 SUS420J1
high speed steel CW6Mo5Cr4V2 M2 1.3342
W6Mo5Cr4V2 M2 1.3343 SKH51
Alloy structural steel 40Cr 5140 1.7035 SCr440
42CrMo 4140 1.7225 MCU 440
40CrNiMoA 4340 1.6511 Microcontroller 439
40CrNiMoA 4340 1.6582
20CrNiMo 8620 1.6523
20CrMn 5120 1.7147
GCr15   1.3505
50CrV 6150 1.8159
Carbon structural steel 45 1045 1.1191 S45C



about Us

about Us

Dongguan Songshun Mold Steel Co., Ltd. is located in Chang'an Town, a famous mold town
Chinese Pearl River Delta Die. After 15 years of development, now we have the ability
Provide a complete service from manufacturing, marketing to distribution. main grade
The tool steel and special steel sold by our company are as follows:

Hot work steel:H13, H21, 1.2714, etc.
Cold work steel:D2, D3, D6, 01, A2, etc.
Plastic mold steel:P20, 1.2738, 1.2083, 1.2767, 1.2312, 1.2316, etc.
High speed steel:M2, M35, M42, etc.
alloy steel:4140, 42CrMo4, 4130, 4340, 8620, 5140, 5160, 6150, 4135, 52100, etc.
Carbon steel:Q235, Q345, 1045, 1084, etc.

As a large wholesaler and retailer, we have an excellent service organization and
First-class marketing personnel, we have been focusing on domestic and foreign markets
Over the years, we have established good and stable business relationships with many overseas customers.

Due to our high quality products, timely delivery, competitive prices and good services, we have won high praise from all our customers.

We always adhere to the concept of "quality first, quality first" and the principle of "equality, fairness and mutual benefit". We sincerely hope to cooperate with more importers to make
Make progress together.





Package
