SML customized high-purity 99.95% tungsten wire vacuum coating funnel tungsten wire stranded wire
- $69.00 /kilogram
- 1 kilogram
- Wuhan Flint Technology Co., Ltd.
- Hubei, China
- Ms Cherry SMLFlint
Product Detail
| application: | Vacuum coating, heating element, filament, heating wire | Wire Gauge: | 0.2-0.5mm |
| Supply capacity: | 100 rolls per day | color: | black, silver, glossy, polished |
| Boiling point: | 5927°C | length: | custom made |
| model: | 99.95% | surface: | Chemical cleaning or electropolishing |
| payment terms: | L/C, D/P, D/A, T/T | type: | heating tungsten wire |
| Melting point: | 3410°C | Wire diameter: | 0.2-1.5mm, customized |
| Origin: | Hubei, China | port: | any port in China |
| brand: | Small ML | purity: | 99.95% minimum |
| product name: | Tungsten stranded wire |
SML customized high-purity 99.95% tungsten wire vacuum coating funnel tungsten wire stranded wire
Product Description
Tungsten has the advantages of high melting point, high resistivity, good strength, low vapor pressure, etc., and is suitable for use as a heater. The thin film material is placed in the heater in the vacuum chamber, and evaporated by the heater (tungsten strand) under high vacuum conditions. When the mean free path of the vapor molecules is greater than the linear dimension of the vacuum chamber, the atoms and molecules of the vapor escape from the surface of the evaporation source with little impact or hindrance from other molecules or atoms. It can directly reach the surface of the substrate to be plated. The temperature of the substrate is low, and the film is condensed. Name Pure tungsten stranded wire Material Pure tungsten and tungsten alloy Surface black, silver, bright, chemical cleaning or electrolytic polishing Application of vacuum coating, heating element, filament, electric light source Size range Single wire diameter: 0.3mm to 1.5mm Twisted wire quantity : 3-4 wires are commonly used, up to 300 wires. How to quote? 1. Single tungsten wire diameter: 0.8mm? 2. How many tungsten wires are twisted together: 1, 2, 3 or 4? 3. Application details: ? 4. Are there any other performance requirements:? 5. Detailed pictures!
Specification
Name | Pure tungsten stranded wire |
Material | Pure Tungsten and Tungsten Alloy |
surface | Black, silver, glossy, chemically cleaned or electropolished |
application | Vacuum coating, heating element, filament, electric light source |
Size range | Single wire diameter: 0.3mm to 1.5mm Tungsten wire stranding quantity: 3-4 wires are popular, up to 300 wires |
How to get a quote? | 1. Single tungsten wire diameter: 0.8mm? 2. How many tungsten wires are twisted together: 1, 2, 3 or 4 wires? 3. Application details: ? 4. Are there any other requirements for performance: ? 5. Detailed pictures! |
characteristic:
1. High density
2. High melting point
3. Low vapor pressure
4. High tensile strength
5. Low coefficient of thermal expansion
6. Excellent electrical conductivity
7. Good machinability
8. High resistance
application
Tungsten wire is commonly used in the manufacture of light bulbs and tungsten wire resistors for lamps. In addition, it can also be used to manufacture optical instruments, electric vacuum components, and high temperature resistant parts.Vacuum coating (picture tube, mirror, plastic, metal substrate, ABS, PP material) heating element filament electric light source
company information
Established in 2008, SML Tools is a leading supplier of tungsten molybdenum alloy metals. Focus on materials with special properties such as high purity, high hardness, and high melting point. After years of development, SML Tools has a variety of products such as plates, cubes, rods, wires, nets, foils, electrodes, evaporation boats, and crucibles now. Our products are not only widely used in traditional industries (aerospace, defense industry, automobile, electronic power, equipment manufacturing), but also widely used in clean energy, thermonuclear energy, LED lighting, medical technology, semiconductor, welding, radio frequency packaging and electronic product. SML Tools has a complete product line to meet your needs, always prioritizing the customer's goals. We're sure you'll agree that SML TOOLS is your best source for alloy metals. shipping
