High temperature fabric coated glass fiber silicone cloth

Product Detail

pack:Roll wrapped in plastic and packed in carton boxexcolor:custom made
Yarn type:Alkali free glassPackaging Details:plastic bag
Surface treatment:silicon coatingsample:freely
place of origin; place of origin:Hebei chinaBraid Type:twill fabric
payment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGramusage:electrical insulation
width:From 1000mm to 2000mmGlass type:E glass fiberglass cloth
Serve:after excellent servicemodel:Silicone Cloth
weight:560 g/m²product name:Silicone Cloth
application:Fiberglass MeshAlkali content:Alkali-free
Supply capacity:100000 pieces per weekMaterial:silicone
Processing services:to cutport:Tianjin/Shanghai
Room temperature:- 70°C to 230°C.brand:Shield
Good features:High temperature resistancethickness:0.44mm

Pu coated glass fiber cloth for thermal insulation and fire protection

Different specifications have different prices

Please consult the customer for the specific price




Pu coated glass fiber clothThe cloth is made of glass fiber cloth, which is processed by coating or calendering. It has the functions of acid and alkali resistance, wear resistance, high and low temperature resistance, and corrosion resistance.

Performance:

1. For - 70°C to 230°C.

2. Ozone resistance, oxygen resistance, light resistance and weather aging resistance, good weather resistance in the field, and a life span of up to 10 years.

3. High insulation performance, dielectric constant 3-3.2, breakdown voltage 20-50kv/MM.

4. Good flexibility, surface friction, good elasticity.

5. Chemical corrosion resistance.

main application:

1. Electrical insulation:Pu coated glass fiber clothThe cloth has a high level of electrical insulation and can withstand high voltage loads. It can be made into insulating cloth, casing and other products.

2. Non-metallic compensator:Pu coated glass fiber clothCloth used as a flexible connection device for pipes. Solve the damage to the pipeline caused by thermal expansion and contraction.Pu coated glass fiber clothThe fabric has high temperature resistance, anti-corrosion, aging resistance, good elasticity and flexibility, and can be widely used in petroleum, chemical, cement, energy and other fields.



3. Anti-corrosion: PU coated with glass fiber cloth can be used as the anti-corrosion layer inside and outside the pipeline, with excellent anti-corrosion performance and high strength. It is an ideal anti-corrosion material.



4. Other fields: PU-coated glass fiber cloth can be used in building sealing materials, high-temperature anti-corrosion conveyor belts, packaging materials and other fields.Pu coated glass fiber clothCloth is also divided into one sidePu coated glass fiber clothcloth and double sidedPu coated glass fiber clothregular color of clothPu coated glass fiber clothThe fabrics are gray, red, blue, black, white, and other colors can also be customized.



thickness

0.42mm, 0.8mm, 1.2mm, 1.5mm, 2.0mm, 3.0mm.

width

1m, 1.2m.

length

50m/roll.
