Fiberglass Sheet Raw Materials
-
$1.30 / 1000 - 9999 kilograms
$1.19 / >=10000 kilograms - 1000 kilograms
- Jiujiang Xingli Beihai Composite Co., Ltd
- Jiangxi, China
- Mr Porter Guo
Product Detail
| Compatible resins: | VE EP, vinyl ester, epoxy and phenolic resins | Fiberglass Type: | Alkali free glass |
| Mat Type: | stitched stamp pad | Glass type: | Electronic Glass CSM |
| Packaging Details: | Each roll is packed in a polybag and put into export carton. | port: | Shanghai |
| Area Weight: | 225g, 300g, 375g, 450g, 600g, 900g/m2. | Origin: | Jiangxi, China |
| application: | boats, bathrooms, auto parts, cooling towers | model: | EMC300/450/600 |
| payment terms: | L/C, Western Union, T/T | width: | 1040mm, 1250mm, etc. |
| feature: | high strength | Processing services: | to cut |
| technology: | E-glass Chopped Strand Mat, Glass Chopped Strand Mat (CSM) | Supply capacity: | 66,000 tons of glass fiber sheet raw materials per month |
| Binder Type: | lotions and powders | Softness: | soft |
| brand: | Beihai, China | product: | Fiberglass Sheet Raw Materials |
| color: | white |
Fiberglass Sheet Raw Materials
| Product Category | |
|---|---|
| powder binder | emulsion adhesive |
describe
Glass Fiber Chopped Strand Mat-Secondemulsion adhesive
E-Glass Emulsion Chopped Strand Mats are made of randomly distributed chopped strands held more tightly by emulsion binders. It is compatible with UP, VE, EP resins. It is compatible with UP, VE, EP, PF resins. Roll widths range from 50mm to 3300mm. Additional requirements for wetting and decomposition times are available upon request. It is designed for hand lay-up, filament winding, compression molding and continuous lamination processes.
Features:
1)Decomposes rapidly in styrene
2) High tensile strength, can be used in hand lay-up process to produce large-area parts
3) Good wetting and fast soaking in resin, fast air penetration
4) Superior acid corrosion resistance
There are two types of glass fiber chopped strand mats: powder binder and emulsion binder.
Get samples and quotes
product specification
| property | Area weight | moisture content | Size content | Breaking strength | width |
| (%) | (%) | (%) | (N) | (mm) | |
| property | IS03374 | ISO3344 | ISO1887 | ISO3342 | 50-3000 |
| EMC80E | ±7.5 | ≤0.20 | 8-12 | ≥40 | |
| EMC100E | ≥40 | ||||
| EMC120E | ≥50 | ||||
| EMC150E | 4-8 | ≥50 | |||
| EMC180E | ≥60 | ||||
| EMC200E | ≥60 | ||||
| EMC225E | ≥60 | ||||
| EMC300E | 3-4 | ≥90 | |||
| EMC450E | ≥120 | ||||
| EMC600E | ≥150 | ||||
| EMC900E | ≥200 |
-
Special specifications can be produced according to customer requirements.
related categories
view related categories
3D fiberglass woven fabric
Fiberglass direct roving
Fiberglass aggregate roving
AR glass fiber roving
Glass fiber chopped strands for thermoplastics
Glass Fiber Chopped Strands for BMC
Grinding Glass Fiber Powder
Fiberglass Seamed Combination Pads
Glass Fiber Chopped Strand Mat
Woven roving
Fiberglass Paper Towel Pads
Fiberglass needle felt
Fiberglass Thermoplastic Products
FRP products
SMC products
Unless otherwise specified, chopped strand mat should be stored in a dry, cool place, protected from rain. It is recommended that the room temperature and humidity be kept at 15°C~35°C and 35%~65% respectively.
Each chopped strand mat is wound on a paper tube with an internal diameter of 76 mm, and the mat roll is 275 mm in diameter. Pad rolls are wrapped in plastic film and then packed in cardboard boxes or wrapped in kraft paper. Volumes can be placed vertically or horizontally. For shipping, rolls can be packed directly into cans or placed on pallets.
End uses include ships, plumbing fixtures, automotive components, chemically resistant piping, storage tanks, cooling towers and building components.
