Refractory aluminum silicate ceramic fiber glass fiber rectangular rope for high temperature oven door sealing

Product Detail

Ultimate Strength (≥MPa):0.5length:25/30/50m
payment terms:L/C, D/P, T/T, Western Unionwidth:not any
thickness:not anystrengthen:Glass or stainless steel wire
type:Round rope, twisted rope, round rope, square ropechemical composition:alumina, silica
Ignition loss (%):18±3Supply capacity:1000 tons per month
Shrinkage (1800℉, 3 hours):-3%brand:Lite
Certification:ISO9001:2008Alumina:≥45%
Operating temperature:650-1050℃Packaging Details:1. Plastic bag inside woven bag 2. According to customer requirements
Bulk density (kg/m3):350 - 620diameter:5-100mm
Organic content:≤15%grade:ST (Standard)
application:insulationThermal Conductivity:<=0.120(W/Mike)
Moisture content:≤2%Origin:Henan, China
pack:woven bag or otherFiber Diameter:2-5μm
port:Qingdao and other major Chinese portsmodel:fiberglass square rope

Refractory aluminum silicate ceramic fiber glass fiber rectangular rope for high temperature oven door sealing



Product Description

What are the details of our fiberglass rectangular rope?

1. Ceramic fiber rope includesSquare Braided Rope, Round Braided Rope, Twisted Twisted Rope.

2. They are made of high qualityceramic fiber material. for ropeglass fiber filament, orStainless steel wire.glass fiber filamentThe reinforced rope can work at the following temperature650°Chave electrical insulation properties, whileStainless steel wirecan work at temperature1100°CHas higher strength.

3. Ceramic fiber textiles (cloth, tape, rope) contain a certain amount of adhesive substances, which generally burn at a relatively low temperature and are notAffect insulation performance.

4.The twisted rope is a soft rope, and the square and round braids are relatively dense..

What is the technical data of our fiberglass rectangular rope?



Classification

1. Ceramic fiber round rope 5-100mm

2. Ceramic fiber square rope 5*5-80*80mm

3. Ceramic fiber twisted rope 10-80mm

strengthen

1. Glass wool

2. Stainless steel wire

Technical data

Aluminum oxide

≥45%

silica

≥46%

Fiber diameter (micron)

2-5

Loss on ignition (%)

18±3

Continuous working temperature (°C)

1.650 (glass filament)

2.1050 (stainless steel wire)

Heat shrinkage rate (%)

<4% (9 hours at 1150°C)

hot Conductivity(%)

<0.20 (800℃)

Bulk density (kg/m3)

350 - 620

product photo

What are the features of our fiberglass rectangular rope?

1. Excellent high temperature stability

2. Excellent tensile strength

3. Excellent thermoelectric insulation

4. Excellent chemical resistance and stability

5. Low thermal conductivity.

What are the applications for our Fiberglass Rectangular Rope?

They are widely used in welding, foundry engineering, aluminum and steel mills, boiler insulation and sealing, exhaust systems, shipyards, refineries, power plants and chemical plants, etc. like

(1) Insulation and sealing of high temperature pipelines

(2) Insulation coating of cables and wires

(3) Coke oven opening seal

(4) Pyrolysis furnace brick wall expansion joints

(5) electric furnace, oven door seal, boiler

(6) High temperature air seal

(7) Flexible expansion joint connection

(8) Furnace curtains and hot zone partitions

Packaging and Shipping

Packing, Shipping, Trade Terms



shipping

1.FedEx/DHL/UPS/TNTsample.



2.Bulk shipments by sea.



3. The customer appoints the freight forwarder or negotiates the transportation method!

4.delivery time:3 days for samples;. Within 7-15 days for bulk goods.

payment terms

1. Payment method:T/T, Western Union, L/C; usually 30% deposit, 70% balancebefore delivery ornegotiationsolve.



2. MOQ: usually 10 rolls.

3. Quality assurance:1 year,

4. Packaging information: 1. Plastic bag inside woven bag 2. According to customer requirements
