54 MM hybrid polypropylene twisted macro synthetic structural fiber for concrete

  • $2.60 / 1000 - 4999 kilograms
    $2.45 / 5000 - 11999 kilograms
    $2.30 / >=12000 kilograms
  • 1000 kilograms
  • Briture Co., Ltd.
  • Anhui, China
  • Mr Thomas Wang

Product Detail

Elastic Modulus:5000MPaminmodel:bound
payment terms:L/C, Western Union, T/Tport:Shanghai
Material:100% polypropylenetensile strength:500Mpa min
Acid and alkali resistance:strongEquivalent diameter (mm):0.3±0.05
use:specificdensity:0.91 g/cm3
Packaging Details:The net weight of PE bag is 1kg; the net weight of each woven bag is 10kg.Supply capacity:50,000 metric tons per year
brand:U.K.Origin:Anhui, China
Fiber length:54mmIgnition point:160-170
Elongation at break:15-20%Melting point:160-170
Product Description

Polypropylene fiber (PP fiber) is made of 100% virgin PP pellets, extruded through different molds and techniques, we can get 4 different types of fibers, including monofilament form, fibril net form, twisted bundle and different Dimensional undulating form. These fibers can effectively improve the reinforcement performance of mortar or concrete, making it strong and protecting the project.


product name
PP fiber bundle
diameter
0.3+/-0.05mm
length
48 / 50 / 54mm...
tensile strength
>560Mpa
crack elongation
15%min
Acid-base
resist
strong

introduce:

1. The fiber is used to replace steel fiber reinforced cement concrete. Compared with steel fiber, it has the advantages of easy dispersion, easy mixing, no damage to mixing equipment, etc.
2. The hard polymer fiber is made of polypropylene, and the surface is roughened by special parallel filament extrusion and twisting process. It has the characteristics of high breaking strength, good dispersion and strong binding force, and will be widely used to replace steel fiber reinforced cement concrete and crack resistance.

Application instructions:

1. Proportion design of fiber concrete:
It is generally recommended that the amount of concrete added is more than 2.7kg per cubic meter (volume ratio is 0.3%), and the amount of steel bars added is 5.5kg. Compared with adding 47kg of steel fibers, the volume ratio of 5.4kg of polymer fibers to steel bars is the same. specific.
2. Length: 54mm, meeting general crack resistance requirements.
3. Proportion:
Usually there is no need to change the mix ratio of the concrete. Considering the anti-cracking requirements, it is recommended to use polymer fibers and PP fiber mesh in combination with a volume ratio of 1:1 (0.9kg fiber mesh per cubic meter of cement concrete).
4. Mixer use: double-shaft horizontal strong mixer is preferred.
5. Mixing process:
Gravel, fiber and sand are put into the mixer in sequence. After stirring for two minutes, the fibers are fully spread, then add cement and water, and stir normally. Adding materials can also be added in the same way as ordinary concrete, but the mixing time should be extended appropriately to make the fibers fully mixed
6. Plastic surgery and maintenance:
There is no special requirement, and the vibration time can be about 30s. The maintenance of fiber concrete is the same as that of ordinary concrete.

application:

1. Roads, bridges, runways, factory grounds.

2. Walls and roofs of tunnels and mines.

3. Dams, rivers, piers, docks and military protection facilities.

Specification
raw material
Polypropylene
fiber type
twisted fascicle
Length (mm)
54
Diameter (microns)
0.3+/-0.05
Strength (Mpa)
>560
Elastic modulus (Mpa)
>5000
Melting point (Celsius)
>15
density
0.91
