Factory hot selling high quality ASTM B760 annealed pure 99.95% tungsten foil tungsten price

Product Detail

application:Industry, medical, metallurgy, high temperature furnace, aerospaceMelting point:3410℃
product name:Factory hot selling high quality ASTM 99.95% tungsten foil tungsten priceCertification:ISO9001
payment terms:Western Union, Wire Transfer, MoneyGram, PayPalport:Changsha, Shanghai, Guangzhou, Shenzhen, Ningbo
purity:W1≥99.95%, W2≥99.92%Boiling point:5927℃
brand:XinkangPackage preview:
Place of origin:Hunan, ChinaMaterial:Tungsten, W1, W2
density:19.3 g/cm3Packaging details:Factory hot selling high quality ASTM B760 annealed pure 99.95% tungsten foil tungsten packaging price: carton or wooden box with good protection, or according to your special requirements.
standard:GB/T3875, ASTM B760model:XK-WF 001
Key words:Tungsten foilSupply capacity:5000kg monthly hot selling high quality ASTM99.95% tungsten foil tungsten price
Product display
Product Description
Factory hot selling high quality ASTM B760 annealed pure 99.95% tungsten foil tungsten price
product name
Factory hot selling high quality ASTM B760 annealed pure 99.95% tungsten foil tungsten price
Material
99.95% tungsten
standard
ASTMB760-07, GB/T3875-83
melting point
3410℃
boiling point
5927℃
density
19.3 g/cm3
technology
cold rolled or hot rolled
delivery time
3-15 days





feature
1. Tungsten foil is made of high-purity 99.95% tungsten material, with a density close to 19.3g/cm3 (theoretical density);
2. The surface of the tungsten sheet has a metallic silver luster;
3. Its radiation shielding effect is equivalent to that of lead plate;
4. Tungsten sheets are easier to process than lead. The board can be cut or punched with household scissors to form any curved shape;
5. Soft, stretchable, foldable, and resistant to repeated bending;
6. Tungsten foil is easy to handle and has no risk of contamination;
7. Has excellent thermoplasticity. Therefore, it can be formed into the shape of a cylindrical surface or a complex curved surface;
8. Xinkang tungsten foil has been vacuum annealed and leveled before leaving the factory.

application
1.Aerospace, electronics, lighting
2. Medical equipment, vacuum coating, electric vacuum furnace electrodes
3. Heat shields, etc. are used as radiation shielding materials and radiation protection equipment.
chemical composition
Impurity content (%), ≤
aluminum
calcium
iron
magnesium
Mo
you
silicon
C
nitrogen
oxygen
0.002
0.005
0.005
0.003
0.01
0.003
0.005
0.008
0.003
0.005
Dimensions and tolerances
thickness
Thickness tolerance
Thickness tolerance
width
Width tolerance
length
Length tolerance
I
two
0.10-0.20
±0.02
±0.03
30-150
±3
50-400
±3
>0.20-0.30
±0.03
±0.04
50-200
±3
50-400
±3
>0.30-0.40
±0.04
±0.05
50-200
±3
50-400
±3
>0.40-0.60
±0.05
±0.06
50-200
±4
50-400
±4
>0.60-0.80
±0.07
±0.08
50-200
±4
50-400
±4
>0.8-1.0
±0.08
±0.10
50-200
±4
50-400
±4
>1.0-2.0
±0.12
±0.20
50-200
±5
50-400
±5
>2.0-3.0
±0.20
±0.30
50-200
±5
50-400
±5
>3.0-4.0
±0.30
±0.40
50-200
±5
50-400
±5
>4.0-6.0
±0.40
±0.50
50-150
±5
50-400
±5
