Tungsten wire 5.8mg tungsten rod for halogen filament
- $2.00 / >=500 kilometers
- 500 kilometers
- Ganzhou Hongfei Tungsten & Molybdenum Materials Co., Ltd.
- Jiangxi, China
- Ms Anna Li
Product Detail
| Packaging Details: | According to customer requirements (carton packing/vacuum packing) | payment terms: | L/C, T/T |
| brand: | Ganzhou Hongfei | Package preview: | |
| Supply capacity: | 15000 km per month | place of origin; place of origin: | Jiangxi, China |
| Wire Gauge: | According to customer requirements | port: | Ganzhou, China |
| model: | W31;WB61;WB91 |
Tungsten wire 5.8mg tungsten rod for halogen filament
This tungsten wire is used in the manufacture of halogen filaments, shock-resistant filaments, and other high-temperature-resistant devices.
1) Type and application
type | application |
WB91 | Used in the manufacture of high temperature resistant devices such as halogen filaments and shock-resistant filaments |
WB61 | Suitable for manufacturing helical coil or triple CFL filaments. |
WB31 | Used in the manufacture of incandescent lamps and supporting wires, etc. |
2) Diameter tolerance
diameter (um) | Weight (mg/200mm) | 200mm weight tolerance | ||
|
| 0 | I | two |
10 | 0.30-0.98 | ---- | ±3.0 | ±4.0 |
18 | 0.98-4.85 | ±2.0 | ±2.5 | ±3.0 |
40 | 4.85-19.39 | ±1.5 | ±2.0 | ±2.5 |
80 | 19.39-272.71 | ±1.0 | ±1.5 | ±2.0 |
300 | 272.71-371.19 | ---- | ±1.0 | ±1.5 |
notes:
The diameter range can be customized according to customer requirements.
The product complies with the technical standard of HFQI-26.
The diameter range can be customized according to customer requirements.
