LUYANG 1260 Ceramic Fiber Wool Paper

Product Detail

length:1000 mm (39.37") minimumapplication:insulation
Package preview:brand:Heron hair
Grading temperature (°C):1260/1350chemical composition:Al2O3:42-47%, SiO2:52-57%
Tensile strength (MPa):0.4/0.7model:LYTX-1260RZ
grade:HP (high purity)Density (kg/m3):200/240
Supply capacity:10 tons per monthUltimate Strength (≥MPa):0.4Mpa
Feature 1:Excellent thermal shock resistanceFiber Diameter:3-5μm
Card:Heron hairThermal Conductivity:0.06-0.12 w/mk
Packaging Details:Inner plastic bag outer cartonDensity (kg/m3):128
port:Qingdao PortCombustion loss (%):≤10/6
payment terms:L/C, D/P, T/TSilica:52-57/49-55
place of origin; place of origin:Shandong ChinaShrinkage (1800℉, 3 hours):-
width:50--1220 mm (1.97--48.03")Feature 2:Easy to machine, cut and shape
product name:0.5mm-10mm thick ceramic fiber paperOperating temperature:1100°C
Alumina:42-47/44-50
Product Description
Luyangmao® ceramic fiber paper/RCF paper
Heron wool® paperIt is made by mixing Luyangwool ® bulk materials, binders and additives. Using a professional papermaking process to form a uniform, flexible paper. Luyangwool ® paper is easy to handle and cut. Luyangwool ® paper can be used as thermal insulation material in a wide range of fields. It is especially suitable for gaskets and as a parting medium. Excellent thermal shock resistance
Easy to machine, cut and shape
high flexibility
low thermal conductivity
good dielectric strength
Typical parameters
describe
Luyang Mao® Standard Paper
Egret® High Definition Paper
Grading temperature (°C)
1260
1350
chemical composition(%)
Aluminum oxide
42-47
44-50
silica
52-57
49-55
color
white
white
Density (kg/m3)
200
240
Tensile Strength (MPa)
0.4
0.7
Combustion loss (%)
≤10
≤6
Thermal conductivity (W/m·K)
200℃
0.06
0.06
400°C
0.09
0.08
600°C
0.13
0.13
800℃
0.20
0.19
1000℃
-
0.29
1200℃
-
0.43
application
typical application
1
Gaskets for High Temperature Applications
2
Household appliance gasket
3
backing for metal slots
4
vehicle insulation box
5
expansion joint
