LUYANG 1260 Ceramic Fiber Wool Paper
-
$62.74 / 1 - 99 rolls
$26.14 / >=100 rolls - 1 roll
- Luyang Energy-Saving Materials Co., Ltd.
- Shandong, China
- Mr Louis LU
Product Detail
| length: | 1000 mm (39.37") minimum | application: | insulation |
| Package preview: | brand: | Heron hair | |
| Grading temperature (°C): | 1260/1350 | chemical composition: | Al2O3:42-47%, SiO2:52-57% |
| Tensile strength (MPa): | 0.4/0.7 | model: | LYTX-1260RZ |
| grade: | HP (high purity) | Density (kg/m3): | 200/240 |
| Supply capacity: | 10 tons per month | Ultimate Strength (≥MPa): | 0.4Mpa |
| Feature 1: | Excellent thermal shock resistance | Fiber Diameter: | 3-5μm |
| Card: | Heron hair | Thermal Conductivity: | 0.06-0.12 w/mk |
| Packaging Details: | Inner plastic bag outer carton | Density (kg/m3): | 128 |
| port: | Qingdao Port | Combustion loss (%): | ≤10/6 |
| payment terms: | L/C, D/P, T/T | Silica: | 52-57/49-55 |
| place of origin; place of origin: | Shandong China | Shrinkage (1800℉, 3 hours): | - |
| width: | 50--1220 mm (1.97--48.03") | Feature 2: | Easy to machine, cut and shape |
| product name: | 0.5mm-10mm thick ceramic fiber paper | Operating temperature: | 1100°C |
| Alumina: | 42-47/44-50 |
Product Description
Luyangmao® ceramic fiber paper/RCF paper
Heron wool® paperIt is made by mixing Luyangwool ® bulk materials, binders and additives. Using a professional papermaking process to form a uniform, flexible paper. Luyangwool ® paper is easy to handle and cut. Luyangwool ® paper can be used as thermal insulation material in a wide range of fields. It is especially suitable for gaskets and as a parting medium. Excellent thermal shock resistance
Easy to machine, cut and shape
high flexibility
low thermal conductivity
good dielectric strength
Easy to machine, cut and shape
high flexibility
low thermal conductivity
good dielectric strength
Typical parameters
describe | Luyang Mao® Standard Paper | Egret® High Definition Paper | ||
Grading temperature (°C) | 1260 | 1350 | ||
chemical composition(%) | ||||
Aluminum oxide | 42-47 | 44-50 | ||
silica | 52-57 | 49-55 | ||
color | white | white | ||
Density (kg/m3) | 200 | 240 | ||
Tensile Strength (MPa) | 0.4 | 0.7 | ||
Combustion loss (%) | ≤10 | ≤6 | ||
Thermal conductivity (W/m·K) | ||||
200℃ | 0.06 | 0.06 | ||
400°C | 0.09 | 0.08 | ||
600°C | 0.13 | 0.13 | ||
800℃ | 0.20 | 0.19 | ||
1000℃ | - | 0.29 | ||
1200℃ | - | 0.43 | ||
application
typical application | ||
1 | Gaskets for High Temperature Applications | |
2 | Household appliance gasket | |
3 | backing for metal slots | |
4 | vehicle insulation box | |
5 | expansion joint | |
