Refractory bricks for glass ovens Clay bricks BBQ pit prices and pizza ovens

Product Detail

shape:brickOrigin:Shandong Province, China
Load softening temperature (0.2MPa) °C:1350 minutesbrand:TK brick
Refractoriness °C:1740 minutesRefractoriness (degrees):Ordinary (1580°
CaO content (%):2%port:Qingdao, Tianjin, Shanghai and other major seaports.
Bulk density g/cm3:2.3-2.4 kg/m3Packaging Details:1. Inner plastic bag, outer carton; 2. Inner plastic bag and packed on pallet; 3. Inner plastic bag, outer carton, and finally packed on pallet
Cold crushing strength Mpa:30 minutesFerric oxide%:2.5 max
Material:Alumina blockAdvantage:High temperature mechanics and chemical resistance
application:Insulation, refractory liningSupply capacity:100,000 tons per month
Processing services:Bending, welding, punching, decoiling, cuttingmodel:TKCLB
Silicon carbide content (%):0Apparent porosity%:up to 24
payment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGramCr2O content (%):0
Silica content (%):50%~65%size:230*114*65mm or customized
Al2O3 content (%):38-42%Certificate:ISO BV
Magnesium oxide content (%):0.8-1.2
Low Price High Alumina Refractory Clay Insulation Brick 230x114x15mm 230x114 For Furnace Lining

Clay brick is a special brick made of refractory clay, which has good high temperature resistance.
For kilns, lining furnaces, fireplaces and fireboxes. These bricks are manufactured in a similar way to regular bricks,
Except during combustion - refractory bricks are exposed to very high temperatures
The refractoriness of the brick is greater than 1580°C.

thing
Low porosity clay refractory brick
DN-10
DN-12
DN-15
DN-17
Alumina/%
≥46
≥45
≥42
≥40
Ferric oxide/%
≤1.1
≤1.2
≤1.5
≤2.0
Bulk density/g/cm3
≥2.40
≥2.37
≥2.30
≥2.25
Refractoriness/℃
≥1700
≥1690
≥1750
≥1770
Load softening temperature/KD ℃
≥1520
≥1500
≥1470
≥1420
Permanent linear change/%
1400℃×2h
+0.0
1400℃×3h
+0.05~-0.10
1400℃×3h
+0.1~-0.2
1400℃×2h

Apparent porosity/%
≤10
≤12
≤15
≤17
Cold crushing strength/Mpa
≥65
≥65
≥55
≥50
Clay refractory brick SK series
thing
SK30
SK32
SK34
SK35
Alumina/%
33%
38%
42%
48%
Ferric oxide/%
≤3
≤3
≤3
≤2.5
Refractoriness/℃
≥1690℃
≥1730℃
≥1750℃
≥1750℃
Bulk density/g/cm3
1.9-2.0
2.0-2.1
2.1-2.18
2.15-2.3
Unit weight (230*114*65mm)
≥3.35KGS
≥3.55KGS
≥3.65KGS
≥3.75KGS
Apparent porosity/%
≤26
≤24
≤24
≤22
cold crushing strength
≥20Mpa
≥25Mpa
≥30Mpa
≥35Mpa
Load softening temperature/℃
≥1250℃
≥1300℃
≥1350℃
≥1420℃
Reheat linear change/%
0~-0.5
(1350℃,2h)
0~-0.3
(1350℃,2h)
0~-0.4
(1450℃,2h)
+0.1~ -0.4
(1450℃,2h)
In addition, we also have SK36, SK37, SK38, SK40 refractories
Choose high alumina bricks. They have a higher aluminum content than clay bricks and can be used at higher temperatures. if your
Kilns require higher temperature and longer service life, it is recommended that you choose refractory high alumina bricks.
