Industrial Boiler Thermal Shock Insulation Refractory Block Thick Plate Lightweight Plate
- $3.00 / >=1000 sets
- 1000 sets
- Shenzhen Bluewind Vermiculite Products Co., Ltd.
- Guangdong, China
- Mr Yusol Cheng
Product Detail
| Bulk density: | 900 kg/m3 | Packaging Details: | Carton packaging and pallet loading; |
| size: | custom made | Origin: | Hebei china |
| CrO content (%): | 0 | payment terms: | L/C, D/P, T/T |
| sample: | usable | raw material: | Expanded Vermiculite |
| Cold Compression Strength: | 6 MPa | Fire load (RUL): | 1100°C |
| feature: | Thermal shock resistance | Silica content (%): | 45-48% |
| port: | Tianjin harbor | Silicon carbide content (%): | 0 |
| Al2O3 content (%): | 13-16% | shape: | jam |
| MgO content (%): | 14-20% | CaO content (%): | 1.5-3% |
| application: | industrial boiler | Processing services: | punching, cutting, forming |
| Refractoriness (degrees): | Ordinary (1580° | brand: | blue wind |
| product name: | vermiculite block | Supply capacity: | 100000 pieces per month |
| model: | V-1200 | Package preview: | |
| Material: | Vermiculite | color: | sand |
Description of Vermiculite Board
feature
heat resistanceup to 1200C
Thermal Conductivity0.18 W/m2
density900 kg/m3
shape: Molded products
Features of condensing gas boiler
no damage
preservative
long lasting
low dimensional tolerance
low cost
no pollutants
high strength
Fire insulation performance
light
Molded parts
thermal battery
The heat chamber is the heart part of the condensing boiler, which determines the service life of the condensing boiler.The 1200℃ vermiculite board can withstand extremely rapid drying and water immersion environments; it has better performance than traditional ceramic fiber boards.
condensing boiler
The ideal service life of a condensing boiler is about 12-15 years, and the heat battery at the heart determines whether it can achieve the ideal life. The use of high-quality vermiculite board can reduce the number of hot core replacements and reduce the worries of users.
For use under harsh conditions, vermiculite boards have excellent mechanical strength, good resistance to thermal spalling, and are highly resistant to chemical attack by volatile alkalis and some slags.
detailed drawing
Product parameters
physical parameters | ||||||
Density (kg/m3) | 700 | 800 | 900 | |||
maximum temperature | 1150°C | 1150°C | 1150°C | |||
strength | 4.5/2.0MPa | 5.5/2.1 MPa | 6.2/2.2MPa | |||
linear shrinkage | 1% | 1% | 1% | |||
Heat Conduction. | ||||||
@200℃ | 0.14 W/m² | 0.16 W/m² | 0.18 W/m² | |||
@ 400°C | 0.16W/square meter | 0.18 W/m2 | 0.2 W/m² | |||
@600℃ | 0.18 W/m² | 0.2 W/m² | 0.22 W/m² | |||
chemical parameters | ||||||
silica | 43-46% | 43-46% | 45-48% | |||
Aluminum oxide | 10-13% | 10-13% | 13-16% | |||
Ferric oxide | 4-6% | 4-6% | 4-6% | |||
Titanium dioxide | 1-2% | 1-2% | 1-2% | |||
magnesium oxide | 16-23% | 16-23% | 14-20% | |||
potassium oxide | 7-10% | 7-10% | 5-8% | |||
Na2O | 1-2% | 1-2% | 1-2% | |||
LOI @ 1000C | 4-6% | 4-6% | 3-5% | |||
Standard Sizes and Thicknesses | ||||||
1005*615mm | 10-60 mm thickness | 10-60 mm thickness | 10-60 mm thickness | |||
1225*615mm | 10-60 mm thickness | 10-60 mm thickness | 10-60 mm thickness | |||
Data are average results of tests performed under standard procedures and are subject to change.
production process
urgent
High pressure molded to desired shape
drying
Dries to release contained moisture and form a stable application
quality inspection
For each unit, we have one by one inspection to ensure the final use.
Product packaging
