Ceramic Fiber Board for Vacuum Forming Parts in High Temperature Furnace
- $1.00 /piece
- 1 piece
- Shandong Robert New Material Co., Ltd.
- Shandong, China
- Ms Yan Zhang
Product Detail
| length: | 900/1200mm | application: | Industrial furnace lining, furnace insulation material, refractory material |
| density: | 220-450 kg/m3 | Origin: | Shandong China |
| Packaging Details: | Packing 1. Inner plastic bag + outer carton 2. Woven bag 3. Ceramic fiberboard plastic bag | Operating temperature: | 1000℃ |
| Thermal Conductivity: | 0.060-0.085 | pack: | carton |
| Name: | Ceramic fiber board for special-shaped parts of high temperature furnace | Pay: | Wire Transfer/Wire Transfer/Wire Transfer |
| Shrinkage (1800℉, 3 hours): | <3% | Fiber Diameter: | 3 microns |
| size: | 25X600X900mm | brand: | Robert |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram, Paypal | chemical composition: | Al2O3≥45% |
| model: | R-ceramic fiberboard | Material: | ceramic fiber block |
| Supply capacity: | 10,000 tons of high-temperature furnace vacuum-formed ceramic fiber boards per month | thickness: | 10-50mm |
| Ultimate Strength (≥MPa): | 0.5 | grade: | HP (high purity) |
| color: | white | port: | Qingdao |
| Keyword two: | ceramic fiberboard | Keyword one: | ceramic fiberboard |
| width: | 400/600/1000mm |
Ceramic Fiber Board for Vacuum Forming Parts in High Temperature Furnace
ceramic fiberboard
Product Details
Ceramic fiberboard refers to hard ceramic fiber products containing inorganic binders. Produced by wet vacuum forming. Due to the use of inorganic binders, the product has excellent mechanical properties and wind erosion resistance, and is generally used to construct the hot surface of industrial furnaces and high-temperature pipeline wall linings.
Ceramic Fiber Board Features:
1. Low heat capacity, low thermal conductivity
2. Non-brittle material, long service life
3. Excellent thermal stability and thermal shock resistance
4. Easy to shape or cut
5. Good wind erosion resistance and uniform distribution.
6. Stable performance, smooth surface, accurate size,
7. Uniform structure and good integrity.
Application of ceramic fiberboard:
1. High temperature reaction, heating equipment backing insulation, heat insulation
2. Kiln backing insulation in petroleum, chemical, metallurgical and other industries
3. Heat treatment kiln backing insulation
4. Non-ferrous metal industrial backing insulation
5. Kiln backing insulation in cement and other building materials industries
6. Industrial kiln wall lining, backing material, kiln masonry expansion joints, furnace door, roof insulation material
1. Inner plastic bag + outer carton
2. Woven bag packaging
3. Plastic bags
